Removal and replacement procedures 33

Drive bay configuration

The server supports a maximum of six internal drives. The two upper drive bays are primarily for

removable media drives, while the four lower drive bays are only for hard drives.

Item Description

1 1

removable media drive

2 2

removable media drive

3 4

SAS/SATA hard drive

4 3

SAS/SATA hard drive

5 2

SAS/SATA hard drive

6 1

SAS/SATA hard drive

7 Removable media drive spare screws

8 HDD spare screws
