Removal and replacement procedures 34

System drive cable management

The figures in this section illustrate the system drives' data and power cable connections. Observe the

proper cable management guidelines described on page 30 when routing the cables.

Data cable management

Item Description

1 SATA cables

2 SAS HDD cable

3 SAS LED cable
