Removal and replacement procedures 42

System board configuration

Refer to the following sections for instructions about how to remove or replace the processor, the

memory modules, the expansion cards, and the system battery. The procedure for installing the

Lights-Out 100c remote management card option is also provided.

Processor

The LGA775 processor socket supports the following processor models:

• Quad-Core Intel Xeon Processor

• Dual-Core Intel Xeon Processor

• Dual-Core Intel Pentium Processor

• Intel Core 2 Duo Processor

• Intel Celeron Processor 400 Sequence

Processor installation guidelines

When configuring the processor, observe the following important guidelines:

• Handle the processor and heat sink fan (HSF) with care. Damage to either may prevent the

system from functioning properly.

• Never touch the processor contact pins; contaminant on the contact pins can damage the

processor.

• Be sure that the server has the most recent ROM version. Failure to flash the ROM before

installing processors can cause system failure.
