Removal and replacement procedures 33
Front USB connectors
To remove the component:
1. Power down the server (on page 26).
2. Remove the bezel ("Bezel" on page 27).
3. Remove the access panel ("Access panel" on page 28).
4. Disconnect the front USB cable from the system board ("System board components" on page 68).
5. Remove the front USB connectors.
To replace the component, reverse the removal procedure.
USB diskette drive
Disconnect a USB diskette drive from the USB connector on the server front panel.
