Removal and Replacement Procedures
4. Loosen the access panel thumbscrews (1).
5. Slide the access panel back about 1.5 cm (0.5 inch), then lift and remove the panel (2).
1
2
Figure 2-4: Loosening the access panel thumbscrews
6. Loosen the two thumbscrews securing the rack bezel to the chassis.
Figure 2-5: Loosening the thumbscrews securing the rack bezel to
the chassis
HP ProLiant ML350 Generation 3 Server Maintenance and Service Guide 2-9
