Connectors, Switches, and LEDs
Table 4-6: System Board LEDs continued
Item Description Status
5 I/O fan status Off = Fan functioning
Amber = Fan is not installed or has failed
6 Processor 2 status Off = Processor 2 functioning
Amber = Processor 2 failed
7 Processor 2 thermal Off = Normal
Amber = Thermal trip detected for processor 2.
Refer to the HP ProLiant ML350 Generation 3
Server Setup and Installation Guide for
the appropriate instructions.
8 PPM 2 status Off = PPM 2 functioning
Amber = PPM 2 failed
9 PCI-X bus 2 speed Off = PCI 33 MHz/PCI-X 66 MHz operating mode
On = PCI 66 MHz/PCI-X 100 MHz operating mode
10 PCI-X bus 2 mode Off = PCI-X mode is inactive
On = PCI-X mode is active
11 Temperature threshold Off = Normal
Amber = Temperature threshold exceeded
12 PCI-X bus 5 speed Off = PCI 33 MHz/PCI-X 66 MHz operating mode
On = PCI 66 MHz/PCI-X 100 MHz operating mode
13 PCI-X bus 5 mode Off = PCI-X mode is inactive
On = PCI-X mode is active
14 CPU fan status Off = Fan functioning
Amber = Fan is not installed or has failed
15 DIMM status (DIMM slots 1
through 4)
Off = DIMM functioning
Amber = DIMM failed
4-12 HP ProLiant ML350 Generation 3 Server Maintenance and Service Guide
