Server Component Identification 13
Item Description Item Description
10 Secondary SCSI connector* 24 Serial port header
11 PPM 2 socket 25 DIMM slot 4
12 RILOE II connector (30-pin) 26 DIMM slot 3
13 System maintenance switch 27 DIMM slot 2
14 64-bit 66 MHz PCI-X slot,
bus 2
28 DIMM slot 1
*For SCSI models only
NMI Jumper
The NMI jumper allows administrators to perform a memory dump before
performing a hard reset. Crash dump analysis is an essential part of eliminating
reliability problems, such as hangs or crashes in operating systems, device
drivers, and applications. Many crashes freeze a system, requiring you to do a
hard reset. Resetting the system erases any information that would support root
cause analysis.
Systems running Microsoft® Windows® operating systems experience a blue
screen trap when the operating system crashes. When this happens, Microsoft®
recommends that system administrators perform an NMI event by pressing a
dump switch. The NMI event enables a hung system to become responsive again.
System Maintenance Switch
Position Default Function
S1 Off Reserved
S2 Off Off = System configuration can be
changed.
On = System configuration is
locked.
