18 HP ProLiant ML350 Generation 4p Server Maintenance and Service Guide

3. Loosen the two thumbscrews on the front panel of the server near the access

panel.

4. Slide the access panel back about 1.5 cm (0.5 in).

5. Lift and remove the access panel.

NOTE: Turn the access panel over to locate the System Configuration

and Options hood labels. These labels will provide information on

installing various options, flexible memory configurations, LED status

indicators, and switch settings.

To replace the component, reverse the removal procedure.

Removing the server from the rack

To remove the server from an HP, telco, or third-party rack:

Power down the server ("Powering down the server" on page 16).

2. Loosen the front panel thumbscrews that secure the server faceplate to the

front of the rack.

3. Disconnect the cabling and remove the server from the rack. Reverse the

server installation steps in the documentation that ships with the rack-

mounting option.

4. Place the server on a sturdy, level surface.
