Removal and replacement procedures 30
4.
Remove the bezel.
To replace the component, reverse the removal procedure.
Rack rails
NOTE: This procedure applies to rack servers only.
To remove the component:
1. Power down the server (on page 26).
2. Remove the server from the rack (on page 27).
3. Use a flat-head screwdriver to lift the spring tab.
4. Slide the rail forward and remove it from the server.
