HP PSC 1500

2 • HP All-in-One
4
5
Attach the control panel overlay (if not attached)
a Bend the bottom of the control panel overlay.
CAUTION: The control panel overlay must be attached for the HP All-in-One to work!
c Lift the lid. Insert the tabs of the overlay into
the device. Make sure the tabs are inserted
correctly before sticking the overlay to the
device.
d Press down on the overlay to ensure it is fi rmly
attached. Do not press on the LCD area. The
tabs must be in the slots.
b Remove the bottom tab and the backing from
the overlay.
Connect the power cord and adapter
Important: Do not connect the USB cable
until instructed later in this guide.
