ENWW 21
B. Technical Specifications
All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
HP LCD Monitors
Face treatment: Glare polarizer with hard coating
Input terminal:
VGA connector
DVI-D 24-pin D-type connector (select models)
Table B-1 Model S1922
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size 47 cm (18.5 in.) diagonal
Tilt -4° (+/-2)~+18° (+/-2)
Maximum Weight (unpacked) 3.2 kg(7.04 lbs)
Dimensions (h x w x d) 340.95 mm x 440.3 mm x 180 mm
13.5 x 17.4 x 7 in
Maximum Graphics Resolution 1366 x 768 @ 60 Hz
Optimum Graphics Resolution 1366 x 768 @ 60 Hz analog mode
Text Mode 720x400
Dot Pitch 0.3 x 0.3 mm/0.01 x 0.01 in
Horizontal Frequency (analog mode) 30 to 83 kHz
Vertical Frequency (analog mode) 55 to 75 Hz
Environmental Requirements
Temperature (independent of altitude)
Operating Temperature 41° to 95° F (5° to 35° C)
Non-Operating Temperature -4° to 140° F (-20° to 60° C)
Relative Humidity (non-condensing)
Operating Humidity 15% to 90%
Non-Operating Humidity 5% to 90%
Power Source 100-240V~, 50/60 Hz
Power Consumption 37 watts (W)
Sleep Power Consumption <1.0 watts (W)
