b. Remove the two Phillips PM2.0×3.0 screws (2) that secure the bezel to the display assembly.
NOTE: The screw covers may be difficult to remove. If you need to replace the covers, they are
available in the Rubber Kit, spare part number 792782-001.
c. Flex the inside edges of the top edge (1), the left and right sides (2), and the bottom edge (3) of
the display bezel until the bezel disengages from the display back cover.
d. Remove the display bezel (4).
The display bezel is available using spare part number 792768-001 for magenta models and
792767-001 for blue models.
7. If it is necessary to replace the webcam/microphone module:
a. Disconnect the webcam/microphone module cable (1) from the module.
Component replacement procedures 41
