Must select min 1 Power Supply
1 - JD220A - HP 384 Gbps A7500 Fab Mod w/2 XFP Ports included min=0 \ max=2 XFP Transceivers
1 - JD229B - HP 48p Gig-T PoE+ Ext A7500 Module included
16U - Height
JG509A
Remarks
BTO Model 1s should never receive an 0D1 and therefore can not be factory integrated into a
rack.
Box Level Integration CTO Models
HP 75xx CTO Switch Solution
JG707A
SSP trigger sku
HP 7502 Switch Chassis CTO
JD242B
Must select min 1 Power Supply
Must select Min 1 Fabric Module
4U - Height
See Configuration Note:
2,3
HP 7503 Switch Chassis - CTO
JD240B
Must select min 1 Power Supply
Must select Min 1 Fabric Module
10U - Height
See Configuration Note:
3,4
HP 7503 Switch Chassis with 1 Fabric Slot - CTO
JD243B
Must select min 1 Power Supply
Must select Min 1 Fabric Module
4U - Height
See Configuration Note:
2,3
HP 7506 Switch Chassis - CTO
JD239B
Must select min 1 Power Supply
Must select Min 1 Fabric Module
13U - Height
See Configuration Note:
3,4
HP 7506 Vertical Switch Chassis - CTO
JD241B
Must select min 1 Power Supply
Must select Min 1 Fabric Module
21U - Height
See Configuration Note:
3,4
HP 7510 Switch Chassis - CTO
JD238B
Must select min 1 Power Supply
Must select Min 1 Fabric Module
16U - Height
See Configuration Note:
3,4
Configuration Rules:
QuickSpecs
HP 7500 Switch Series
Configuration
DA - 13805 Worldwide — Version 29 — December 9, 2013
Page 10
