HP TouchSmart 9300 Elite Quickspecs

Display 23-inch diagonal widescreen WLED backlit BrightView LCD
Multi-touch panel
Resolution 1920 x 1080 resolution (16:9), Full HD (1080p)
Aspect ratio 16:9
Touch Panel accuracy USB reported touch resolution 32767 x 32767
Contrast ratio 1000:1
Image brightness 250 nits typical
Vertical viewing angle 178 degrees
Horizontal viewing angle 178 degrees
Adjustable Reclining
Stand
Tilt angle -5º to +60º to the vertical plane
Fully reclined position 30º from horizontal
Memory Standard Configurations PC3-10600 DDR3 non-ECC SDRAM (runs at 1333 MHz)
Four 204-pin SODIMM slots supporting dual channel memory
2 GB SODIMMs (up to 4 for 8 GB memory)
4 GB SODIMMs (up to 4 for 16 GB memory)
Maximum memory Upgradeable to up to 16 GB using four (4) 4 GB SODIMMs
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
NOTE: Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-
bit operating systems, the amount of usable memory is dependent upon your configuration, so that above
3 GB all memory may not be available due to system resource requirements.
Communications Realtek 8111EDL
Ethernet Connection
Integrated 10/100/1000 NIC *
HP 802.11 PCIe Minicard
Wireless Module
(optional)
Support for 802.11 b, g, and n
Up to 300 mbps data rate
Built-in dual antennas
Intel Centrino Advanced-
N 6205 Wireless Network
Interface Connection PCIe
Minicard (optional)
Support for 802.11 a, b, g, and n
Up to 300 mbps data rate
Built-in dual antennas
Bluetooth Wireless
Technology (optional)
Bluetooth 3.0 compliant
Works with a wide range of Bluetooth devices
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
QuickSpecs
HP TouchSmart 9300 Elite All-in-One PC
Standard Features
DA - 13903 North America — Version 17 — July 26, 2012 Page 5

HP TouchSmart 9300 Elite Specifications

General

RAM	Up to 16 GB DDR3 SDRAM
Operating System	Windows 7 Professional
Touchscreen	Yes
Processor	Intel Core i5 or i7
Display	23-inch diagonal widescreen LCD with LED backlight
Storage	Up to 1 TB Hard Disk Drive or Solid State Drive
Graphics	Intel HD Graphics
Optical Drive	DVD+/-RW SuperMulti DL
Chipset	Intel Q67 Express
Audio	Integrated high-definition audio
Webcam	Integrated 2 MP webcam
Ports	USB 2.0, RJ-45, audio in/out
Networking	Gigabit Ethernet, Wi-Fi
