HP Vp15 Service Manual

15" LCD Color Monitor HP VP15
131
CN001 033G803210D WAFER
CN001 033G803210S WAFER
C002 065G0603102 32 1000PF +-10% 50V X7R
C001 065G0603102 32 1000PF +-10% 50V X7R
C007 065G0603102 32 1000PF +-10% 50V X7R
C003 065G0603102 32 1000PF +-10% 50V X7R
C004 065G0603102 32 1000PF +-10% 50V X7R
C005 065G0603102 32 1000PF +-10% 50V X7R
C006 065G0603102 32 1000PF +-10% 50V X7R
C008 065G0603102 32 1000PF +-10% 50V X7R
SW001 077G 606 21HJ TACT SW 4PIN SMT TSXH-3GL
SW002 077G 606 21HJ TACT SW 4PIN SMT TSXH-3GL
SW003 077G 606 21HJ TACT SW 4PIN SMT TSXH-3GL
SW004 077G 606 21HJ TACT SW 4PIN SMT TSXH-3GL
ZD001 093G 39S 34 T UDZSNP5.6B ROHM
ZD002 093G 39S 34 T UDZSNP5.6B ROHM
ZD003 093G 39S 34 T UDZSNP5.6B ROHM
ZD004 093G 39S 34 T UDZSNP5.6B ROHM
715G2283 1 K KEY BOARD PCB
KEPC6AA7P KEY BOARD
CN004 033G8032 4C WAFER
SW005 077G 607 1 FD TACT SWITCH
LED001 081G 14 20 AV LED AQUA WHITE / AMBER
ZD007 093G 39S 34 T UDZSNP5.6B ROHM
ZD005 093G 39S 34 T UDZSNP5.6B ROHM
ZD006 093G 39S 34 T UDZSNP5.6B ROHM
715G2283 1 P KEY BOARD PCB
PWPC521SH1P POWER BOARD
CN801 033G8020 2D U WAFER
CN802 033G8020 2D U WAFER
040G 45762420A LABEL 25x6mm
IC902 056G 139 7 1 IC EL817MA M-TYPE
IC902 056G 139 3A IC PC123Y22FZ0F
R920 061G152M688 64 0.68OHM +-5% 2W
C903 063G 10747410V 0.47UF 275VAC ARCO
C816 065G 3J1506ET 15PF 5% CC45SL 3KV TDK
C802 065G 3J2096ET 2PF 5% SL 3KV
C901 065G305M1022E2 1000P 400VAC/250VAC
C902 065G305M1022E2 1000P 400VAC/250VAC
C901 065G305M1022EM Y2 1000PF +-20% 250VAC
