19" LCD Color Monitor HP VS19E
15
6.3.2 Inverter / Power Board
EMI filter
Bridge
Rectifier
and Filter
Start Circuit
R912/R916/R918
PWM
Control IC
Transformer
Over
Voltage
Protect
Diode
Rectifier&filter
5V
12V
Start
circuit
OZ1060
PWM IC
Feedback
Circuit
LC
resonance
Full bridge
switch circuit
Lamp
ON/OFF
DIM
CON102
