64
4. Configure VRRP on Router A:
# Create VRRP group 1, and configure the virtual IP address 10.1.1.10 for the group.
[RouterA] interface gigabitethernet 1/0
[RouterA-GigabitEthernet1/0] vrrp vrid 1 virtual-ip 10.1.1.10
# Set the priority of Router A in VRRP group 1 to 110.
[RouterA-GigabitEthernet1/0] vrrp vrid 1 priority 110
# Set the authentication mode of VRRP group 1 to simple, and the authentication key to hello.
[RouterA-GigabitEthernet1/0] vrrp vrid 1 authentication-mode simple plain hello
# Configure the master to send VRRP packets at an interval of 500 centiseconds.
[RouterA-GigabitEthernet1/0] vrrp vrid 1 timer advertise 500
# Configure Router A to operate in preemptive mode, and set the preemption delay to 5 seconds.
[RouterA-GigabitEthernet1/0] vrrp vrid 1 preempt-mode delay 5
# Configure to monitor track entry 1 and specify the priority decrement to 30.
[RouterA-GigabitEthernet1/0] vrrp vrid 1 track 1 reduced 30
5. Configure VRRP on Router B:
<RouterB> system-view
[RouterB] interface gigabitethernet 1/0
# Create VRRP group 1, and configure the virtual IP address 10.1.1.10 for the group.
[RouterB-GigabitEthernet1/0] vrrp vrid 1 virtual-ip 10.1.1.10
# Set the authentication mode of VRRP group 1 to simple, and the authentication key to hello.
[RouterB-GigabitEthernet1/0] vrrp vrid 1 authentication-mode simple plain hello
# Configure the master to send VRRP packets at an interval of 500 centiseconds.
[RouterB-GigabitEthernet1/0] vrrp vrid 1 timer advertise 500
# Configure Router B to operate in preemptive mode, and set the preemption delay to 5 seconds.
[RouterB-GigabitEthernet1/0] vrrp vrid 1 preempt-mode delay 5
Verifying the configuration
After configuration, ping Host B on Host A, and you can see that Host B is reachable. To view the
configuration result, use the display vrrp command.
# Display detailed information about VRRP group 1 on Router A.
[RouterA-GigabitEthernet1/0] display vrrp verbose
IPv4 Virtual Router Information:
Running Mode : Standard
Total number of virtual routers : 1
Interface GigabitEthernet1/0
VRID : 1 Adver Timer : 500
Admin Status : Up State : Master
Config Pri : 110 Running Pri : 110
Preempt Mode : Yes Delay Time : 5
Auth Type : Simple Key : ******
Virtual IP : 10.1.1.10
Virtual MAC : 0000-5e00-0101
Master IP : 10.1.1.1
VRRP Track Information:
Track Object : 1 State : Positive Pri Reduced : 30
