HP W1907 User Manual

User’s Guide 5–1
5
Preparing the Monitor for Shipping
Keep the original packing box in a storage area. You may need it later if you move or ship your monitor.
You may need to detach the monitor base when you ship the HP LCD monitor.
Removing the Monitor Base
Å
WARNING: Do not remove the base from the pedestal while the monitor is standing in the upright position.
Attempting to remove the base from the pedestal while the monitor is upright might injure the user.
Å
WARNING: Before disassembling or folding the monitor, turn off the monitor power, and disconnect all power,
video, and audio cables. To disconnect power from the equipment, unplug the power cord from the power outlet by
grasping the power plug firmly. Never pull on the cord.
Ä
CAUTION: The screen is fragile. Placing the monitor screen down on a flat, soft area prevents scratches, defacing,
or breakage. Avoid applying pressure to the LCD screen; doing so can cause damage.
Removing the cantilever base
1. Disconnect the power, video, and audio cables from the monitor.
2. Set the monitor screen down on a flat, soft, protected surface.
3. Press the center tab in (1) and detach the base from the monitor (2).
Removing the cantilever base

HP W1907 Specifications

General

Pixel pitch	0.285 x 0.285 mm
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Viewable size diagonal	483 mm
Contrast ratio (typical)	1000:1
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Power requirements	100-240VAC
HDCP	Yes
Certification	FCC Class B
Product color	Silver
Country of origin	China
Market positioning	-
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	49 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	15 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	182 mm
Width (without stand)	452 mm
Height (without stand)	378 mm
Weight (without stand)	5000 g
