HP x4000 - Hard Disk Drive Cage; Opening the Hard Disk Drive Cage

Installing or Replacing Parts and Accessories
Hard Disk Drive Cage
Chapter 10 149
Hard Disk Drive Cage
Opening the Hard Disk Drive Cage
To open the cage (Figure 10-3):
1. Disconnect the SCSI cable(s) and power cable(s) from the hard disk
drive(s).
CAUTION Do not rotate the cage before you disconnect the cables.
2. Remove and retain the two torx screws that hold the cage closed as
shown in Figure 10-3.
3. Pull the cage toward you until you hear the hard disk drive cage clip
catch the cage.
WARNING Confirm the clip has latched the cage in the open position.
Injury could be result if the cage falls.
