HP x4000 - Page 98

Connector Pin-Outs
Expansion Slots
Chapter 798
A13 A60 P64REQ64#
A14 3.3VSB A61 +5V
A15 P64RST# A62
A17 P64AD21R P64AD20R A63 GND
A18 GND A64 P64CBE7#
A19 P64PME# A65 P64CBE5#
A20 P64AD30 A66 +3_3V
A21 +3_3V A67 P64PAR64
A22 P64AD28 A68 P64AD62
A23 P64AD26 A69 GND
A24 GND A70 P64AD60
A25 P64AD24 A71 P64AD58
A26 P64AD21R P64AD20R A72 GND
A27 +3_3V A73 P64AD56
A28 P64AD22 A74 P64AD54
A29 P64AD20 A75 +3_3V
A30 GND A76 P64AD52
A31 P64AD18 A77 P64AD50
A32 P64AD16 A78 GND
A33 +3_3V A79 P64AD48
A34 P64FRAME# A80 P64AD46
Table 7-2 PCI 66 MHz, 64-bit Connector
Pin
Signal
Pin
Signal
Slot #1
(J4B1)
Slot #2
(J3B1)
Slot #1
(J4B1)
Slot #2
(J3B1)
