Product Description
Maintenance and Service Guide 1ā9
5 Composite video jack Connects an optional composite video
device.
6 S/PDIF (Sony/Philips
Digital Interface) digital
audio jack
Connects an optional compatible
audio/video receiver through a digital
coaxial cable (purchased separately).
7 External monitor port Connects an optional external VGA
monitor or projector.
8 RJ-45 (network) jack Connects an Ethernet cable from the
expansion base to an RJ-45 wall jack.
9 Hard drive power
connector
Connects the power cord for the optional
internal hard drive.
10 Security cable slot Attaches an optional security cable to the
expansion base.
ā
The security cable is designed to
act as a deterrent, but it may not
prevent the expansion base from
being mishandled or stolen.
11 Hard drive carrier screw Secures the hard drive carrier for the
optional internal hard drive.
12 Expansion cable Connects the expansion base to a
computer.
13 Connection indicator
light
On: The computer is connected correctly.
*There are 2 additional USB ports on the right side of the expansion base.
Table 1-4
Rear Panel Components
(Continued)
Item Component Function
