3/12
Installing an IEEE-1394 card
Step 2—Remove PCI slot cover
Open the PCI retention clamp by pressing down on the clips and moving the clamp toward the rear of the
workstation 1. Pull up on the slot cover to remove it from the chassis 2.
✎
NOTE: The following illustrations are shown as examples only. Your system may look different.
Figure 1 Remove PCI slot cover
