4/12
Installing an IEEE-1394 card
Step 3—Install the IEEE-1394 card
Ä
CAUTION: To prevent damage to this system, observe the following Electro Static Discharge (ESD) precautions
while performing the system parts removal/replacement procedures:
❏ Work on a static-free mat.
❏ Wear a static strap to ensure that any accumulated electrostatic charge is discharged from your body
to the ground.
❏ Create a common ground for the equipment you are working on by connecting the static-free mat,
static strap and peripheral units to that piece of equipment.
Install the IEEE-1394 card 1 in an unused PCI or PCI Express slot that accommodates the type of
IEEE-1394 card you are installing. Lower the PCI retention clamp and close the retention clamp clips 2.
Figure 2 Install IEEE-1394 card
