Intel 975X Express chipset
Intel 975X Express chipsetIntel 975X Express chipset
Intel 975X Express chipset
PC2-5300E DDR2-667 or PC2-5300U DDR2-667DIMMS
PC2-5300E DDR2-667 or PC2-5300U DDR2-667DIMMSPC2-5300E DDR2-667 or PC2-5300U DDR2-667DIMMS
PC2-5300E DDR2-667 or PC2-5300U DDR2-667DIMMS
Only unbuffered DDR2 DIMMs (ECC unbuffered or non-ECC) are supported and must be either x8 or x16 width. Memory upgrades
are accomplished by adding DIMMs of the same or varied sizes. The Intel 975X chipset supports both PC2-5300 DDR2-667 non-
ECC and ECC unbuffered memory.
For best performance the total amount and type of memory loaded into Channel A and Channel B should be the same. If it is not,
your computer will see all the RAM installed but will run the memory controller at a lower performance mode. Although not required,
for best performance add the memory in pairs rather than as a single DIMM (two 512 MB DIMMs will have better performance than
a single 1 GB DIMM). Also, add the memory into both channels (e.g. one in socket 1 and one in socket 3) to take advantage of dual
channel performance. If you have unused slots within a channel, make them socket 2 and socket 4. This provides the best margin for
the memory bus. If you are only using 1 DIMM, install it in socket 1.
MAXIMUM MEMORY
MAXIMUM MEMORYMAXIMUM MEMORY
MAXIMUM MEMORY
Supports up to 8 GB DDR2-667 ECC Unbuffered or 2 GB DDR2-667 non-ECC SDRAM
POSSIBLE MEMORY CONFIGURATIONS
POSSIBLE MEMORY CONFIGURATIONSPOSSIBLE MEMORY CONFIGURATIONS
POSSIBLE MEMORY CONFIGURATIONS
Not all memory configurations possible are represented below.
DIMM Size
DIMM SizeDIMM Size
DIMM Size
Slot
SlotSlot
Slot
1
11
1 2
22
2 3
33
3 4
44
4
256 MB
(single channel performance configuration)
256 MB
512 MB 256 MB
256 MB
1 GB
512 MB
512 MB
1.5 GB
256 MB 512 MB 256 MB 512 MB
2 GB 1 GB
1 GB
2 GB
512 MB 512 MB 512 MB 512 MB
4 GB 1 GB
1GB
1 GB
1GB
4 GB 2 GB
2 GB
6 GB 1 GB 2 GB 1 GB 2 GB
8 GB 2 GB 2 GB 2 GB 2 GB
QuickSpecs
HP xw4400 Workstation
HP xw4400 WorkstationHP xw4400 Workstation
HP xw4400 Workstation
Memory
DA - 12568 Canada — Version 12 — March 2, 2007
Page 20
