HP xw4400 Quickspecs

Form Factor
Form FactorForm Factor
Form Factor Minitower
Colour
ColourColour
Colour Carbonite/Alloy metallic
Convertibility
ConvertibilityConvertibility
Convertibility Yes. 5.25" drives rotate for Minitower or Desktop orientation.
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots (see
mainboard section for
more details)
3 PCI slots (full-height, full-length)
1 PCI Express x16 slot (x4 functionality)
1 PCI Express x1 slot
1 PCI Express x16 graphics slot
Expansion Bays
Expansion BaysExpansion Bays
Expansion Bays (see
storage section for more
details)
2 internal 3.5" bays
1 external 3.5" bay, 3 external 5.25" bays*
NOTE:
NOTE: NOTE:
NOTE: Third external 5.25" bay is not full depth in side orientation.
Front I/O
Front I/OFront I/O
Front I/O 2 USB 2.0, 1 IEEE 1394 (requires optional PCI card to function), 1 audio out, and 1 microphone.
NOTE:
NOTE: NOTE:
NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux Hardware
Support Matrix ( http://www.hp.com/support/linux_hardware_matrix ) for details, and to the Linux User
Manual ( http://www.hp.com/support/linux_user_manual ) for tips on user-enablement of the IEEE 1394
Card.
Internal I/O
Internal I/OInternal I/O
Internal I/O 1 USB 2.0 header
Rear I/O
Rear I/ORear I/O
Rear I/O 5 USB 2.0, 1 serial, 1 optional serial port, parallel port, 2 PS/2, RJ-45 (NIC), 1 audio in, 1 audio out, 1
microphone inches; audio/microphone ports can be made to function autosensing and interchangeably
retaskable by downloading a driver)
USB Keyboard
USB KeyboardUSB Keyboard
USB Keyboard Optional
USB Mouse
USB MouseUSB Mouse
USB Mouse Optional
PS/2 Keyboard
PS/2 KeyboardPS/2 Keyboard
PS/2 Keyboard 1
PS/2 Mouse
PS/2 MousePS/2 Mouse
PS/2 Mouse 1
Interfaces Supported
Interfaces SupportedInterfaces Supported
Interfaces Supported 1 SATA 3 Gb/s interface (4 SATA connectors), 1 EIDE interface for optical drives
Hard Drive Controller
Hard Drive ControllerHard Drive Controller
Hard Drive Controller
(PCI) Supported
SupportedSupported
Supported
Optional Ultra320 or Ultra320 RAID (Hardware RAID is not supported on Linux systems. The Linux
kernel, with built-in software RAID, provides excellent functionality and performance. It is a good
alternative to hardware-based RAID. Please visit
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf for RAID
capabilities with Linux.)
On-board RAID Support
On-board RAID SupportOn-board RAID Support
On-board RAID Support Yes
Chassis Dimensions
Chassis DimensionsChassis Dimensions
Chassis Dimensions
(H x W x D)
17.7 x 6.6 x 17.9 inches; 45.0 x 16.8 x 45.6 cm
6.6 x 17.7 x 17.9 inches; 16.8 x 45.0 x 45.6 cm
Weight
WeightWeight
Weight From 35.0 lb (15.88 kg), depending on configuration
Shipping Weight
Shipping WeightShipping Weight
Shipping Weight From 44.0 lb (19.96 kg), depending on configuration
Temperature
TemperatureTemperature
Temperature Operating 40° to 95°F (5° to 35°C)
Non-operating -40° to 140°F (-40° to 60°C)
Humidity
HumidityHumidity
Humidity Operating 8% to 85%
Non-operating 8% to 90%
Maximum Altitude
Maximum AltitudeMaximum Altitude
Maximum Altitude (non-
pressurized)
Operating 10,000 feet; 3,000 m
Non-operating 30,000 feet; 9,100 m
Power Supply
Power SupplyPower Supply
Power Supply 460 watts wide-ranging, active Power Factor Correction
QuickSpecs
HP xw4400 Workstation
HP xw4400 WorkstationHP xw4400 Workstation
HP xw4400 Workstation
Standard Features - Specs
DA - 12568 Canada — Version 12 — March 2, 2007 Page 9

HP xw4400 Specifications

General

Processor	Intel Core 2 Duo
Chipset	Intel 975X
Memory	Up to 8 GB DDR2
Storage	SATA 3.0 Gb/s
Graphics	NVIDIA Quadro FX series
Operating System	Windows XP Professional
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 3 PCI
Ports	6 USB 2.0, 2 PS/2, 1 serial, 1 parallel, 1 RJ-45
Optical Drive	DVD-ROM
