SAS rear panel cable installation
2. Use a mounting screw 2 to attach the MiniSAS 4X connector of the SAS rear panel cable assembly to
the rear of the chassis.
2
1
Figure 2 Attach MiniSAS 4X connector
3. Adhere the external SAS label to the outside of the chassis near the connector.
Figure 3 Adhere label to chassis
