HP Z1 G2 Product End-Of-Life Disassembly Instructions

d)remove left & right MIC phone and disassembly connector
e) Use T5 screw driver to disassemble
the screw
f)disassembly connector
g) disassembly finish
23)remove latch
a) Use T15 screw driver to disassemble
the screw
b) Use T15 screw driver to
disassemble the screw
c)pull the spring structure to release
the latch
d) Use T15 screw driver to disassemble
the screw
e) disassembly finish
24)remove Touch plan
a) Use T15 screw driver to disassemble the screw
EL-MF877-00 Page 13
Template Revision B
PSG instructions for this template are available at EL-MF877-01
