HP Z200 Overview

Intel Xeon Processor X3470 2.93 GHz, 8MB cache, 1333 MHz
memory, Quad-Core, HT, Turbo
Y N
Intel Xeon Processor X3480 3.06 GHz, 8MB cache, 1333 MHz
memory, Quad-Core, HT, Turbo
Y N
Integrated Intel HD graphics is supported only on Dual-Core Intel® "Clarkdale" Processors; it is not
supported on the Quad-Core Intel Core i5-700 Desktop Processor Series, Intel Core i7-800 Desktop
Processor Series or Intel Xeon Processor 3400 Series.
Hard Drives
SATA Hard Drives
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
SATA (Serial ATA) Hard Drives for HP Workstations
160GB SATA 7200 rpm 3Gb/s 3.5" HDD Y Y PV944A
250GB SATA 7200 rpm 3Gb/s 3.5" HDD (for HP Z-
Workstations)
Y Y PY278AA
320GB SATA 7200 rpm 3Gb/s 3.5" HDD Y Y FH963AA
500GB SATA 7200 rpm 3Gb/s 3.5" HDD Y Y PV943A
1000GB (1TB) SATA 7200 rpm 3.0Gb/s 3.5" HDD Y Y GE262AA
1.5TB SATA 7200 rpm 3Gb/s 3.5" HDD Y Y VH997AA
160GB SATA 10K rpm SFF in 3.5" Frame HDD Y Y EW222AA
300GB SATA 10K rpm SFF in 3.5" Frame HDD Y Y FM802AA
SATA Solid State Drives HP Solid State Drives for Workstations
HP 160GB SATA X25-M SSD Y Y WV915AA
Hard Drive Controllers
Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
Integrated SATA 3.0 Gb/s Controller (Z200)
Integrated SATA 3.0 Gb/s Controller, RAID 0, 1, 5
supported
Y N
Factory integrated RAID on motherboard for SATA drives
RAID 0 Data Configuration -- Boot/OS Drive + 2 Drive
Striped Array
Y N
RAID 0 Configuration - Striped Array Y N
RAID 1 Configuration - Mirrored Array Y N
SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,
provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please
visit: http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf for RAID
capabilities with Linux.
All drives must be identical in type and capacity
All RAID arrays must be less than 2 TB
NOTE 1: Requires identical hard drives (speeds, capacity, interface).
QuickSpecs
HP Z200 Workstation
Supported Components
DA - 13541 Worldwide — Version 20 — September 1, 2011 Page 6

HP Z200 Specifications

General

Tcase	69.1 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1240
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Maximum internal memory	- GB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	-
Graphics card	Quadro 2000
Power supply type	AC
External drive bays	3 x 5.25\
Internal drive bays	3 x 3.5\
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum graphics card memory	1.024 GB
Modem (RJ-11) ports	0
PS/2 ports quantity	2
USB 2.0 ports quantity	14
Chassis type	Minitower
Product color	Black
Country of origin	China
Number of 3.5\" bays	3
Bundled software	HP ProtectTools
Operating system installed	Windows 7 Professional
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Power supply	400 W
Power supply input voltage	100-240 V
Power supply input frequency	50 - 60 Hz
Certification	ENERGY STAR 5.0
Processor code	SR00K
Processor ARK ID	52273
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	455 mm
Width	178 mm
Height	447 mm
Weight	10400 g
