HP Z22n G2 User Manual

30
10. Mechanical Instructions
Step
Figure
Description
Remove the
HINGE ASS'Y
Press the button
to remove the
hinge assy
Remove the
REAR_COVER
Remove the
screws first,and
remove the rear
cover ,then
remove the key
board from rear
cover

HP Z22n G2 Specifications

General

3D	No
Pixel pitch	0.247 x 0.247 mm
Screen shape	Flat
Display diagonal	21.5 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Horizontal scan range	30 - 84 kHz
Viewable size, vertical	267.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+)
Pivot angle	0 - 90 °
Tilt angle range	-5 - 22 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Product color	Black
Country of origin	China
Market positioning	Business
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	30 W
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	17 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
USB Type-A downstream ports quantity	2
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	205 mm
Height (with stand)	448.7 mm
Weight (with stand)	5300 g
Depth (without stand)	43.3 mm
Width (without stand)	488.3 mm
Height (without stand)	293.3 mm
Weight (without stand)	2800 g
