HP Z30i User Manual

Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 166 BTU/hr 164 BTU/hr 168 BTU/hr
Sleep 2 BTU/hr 2 BTU/hr 2 BTU/hr
Off 1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
gold level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 17.2 % post-consumer recycled plastic (by wt.)
This product is 98.3 % recycle-able when properly disposed of at end of
life.
Packaging Materials External: PAPER/Corrugated 2178 g
Internal: PLASTIC/EPS (Expanded
Polystyrene)
720 g
PLASTIC/Polystyrene High
Impact
61 g
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental
laws and regulations, including the European Union Restriction of Hazardous
Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by
meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances will be virtually eliminated (virtually = to levels below
legal limits) for all HP electronic products subject to the RoHS Directive, except
where it is widely recognized that there is no technically feasible alternative (as
indicated by an exemption under the EU RoHS Directive).
Material Usage This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/
gse.pdf ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
QuickSpecs
HP Z30i 30-inch IPS Display
Technical Specifications
DA - 14755 North America — Version 3 — January 16, 2014 Page 6

HP Z30i Specifications

General

3D	No
HD type	-
Pixel pitch	0.250 x 0.250 mm
Aspect ratio	16:10
Response time	8 ms
Backlight type	W-LED
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Display technology	LED
Vertical scan range	60 - 70 Hz
Horizontal scan range	31 - 80 kHz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	50 - 70 Hz
Digital horizontal frequency	24 - 98 kHz
Display brightness (typical)	350 cd/m²
On/off switch	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-I ports quantity	0
USB Type-A downstream ports quantity	5
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	125 W
Power consumption (standby)	0.5 W
Power consumption (typical)	85 W
Certification	CE, CB, CEL, KC, KCC, NOM, PSB, ICE, TUV-S, CCC, CECP, SEPA, TCO 6.0, EPA, ISC, VCCI, FCC, HSMI
Product color	Black
Country of origin	China
Market positioning	Business
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Package weight	13730 g
Cables included	DisplayPort, DVI, USB
Sustainability certificates	EPEAT Gold, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	266.4 mm
Height (with stand)	601 mm
Weight (with stand)	9960 g
Depth (without stand)	66.3 mm
Width (without stand)	690.3 mm
Height (without stand)	449.8 mm
Weight (without stand)	7560 g
