HP Z400 Quickspecs

Integrated Trusted
Platform Module
Integrated TPM 1.2
Power Supply
Headers
Yes
Power Switch, Power
LED & Hard Drive LED
Header
Yes
Clear Password
Jumper
Yes
Serial Port Single Port (Requires optional Serial Port Adapter)
Parallel Port No
Keyboard/Mouse USB or PS/2
Hood Lock Header Yes
Hood Sensor Header Yes
Z400 Required power supply info
Power Supply 475W Custom PSU -
(Wide Ranging, Active PFC)
600W Custom PSU -
(Wide Ranging, Active PFC)
Operating Voltage Range 90 - 269 VAC 90 - 269 VAC
Rated Voltage Range 100 - 127 VAC
200 - 240 VAC
118 VAC 100 - 127 VAC
200 - 240 VAC
118 VAC
Rated Line Frequency 50-60 Hz 400Hz 50-60 Hz 400Hz
Operating Line Frequency Range 47 - 66 Hz 393-407 Hz 47 - 66 Hz 393-407 Hz
Rated Input Current 10A @ 100-127 VAC
6A @ 200-240 VAC
10A @ 118 VAC 10A @ 100-127 VAC
6A @ 200-240 VAC
10A @ 118 VAC
Heat Dissipation
(Configuration & software
dependent)
Typical 954 btu/hr (240.3 kg-cal/hr)
Max 1977 btu/hr (498.2 kg-cal/hr)
Typical 1536 btu/hr (387 kg-cal/hr)
Max 2560 btu/hr (645 kg-cal/hr)
Power Supply Fan 92x25 mm variable speed 92x25 mm variable speed
ENERGY STAR Qualified
(Configuration dependent)
YES NO
80 PLUS® Compliant YES, 85% YES, 80%
FEMP Standby Power Compliant
@115V (Wake-on LAN disabled)
(<2W in S5 - Power Off)
YES YES
EuP Compliant @ 230V
(<1 W in S5 - Power Off)
YES YES
Power Consumption in sleep mode
(as defined by ENERGY STAR) -
Suspend to RAM (S3) (Instantly
Available PC) measured at 115V.
<6W <6W
Built-in Self Test LED YES YES
QuickSpecs
HP Z400 Workstation
System Technical Specifications
DA - 13276 North America — Version 58 — November 21, 2013 Page 15

HP Z400 Specifications

General

Bus type	QPI
Processor cache	4 MB
Processor cores	2
Processor model	W3503
System bus rate	4.8 GT/s
Processor socket	-
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Number of processors installed	1
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Audio system	Realtek ALC262
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Memory layout (slots x size)	- GB
Graphics card	Quadro 600
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
HDD speed	- RPM
RAID levels	0, 1, 5, 10
HDD capacity	500 GB
HDD interface	SATA II
Storage media	HDD
Display included	No
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Minitower
Country of origin	China
Number of 5.25\" bays	3
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
Power supply	475 W
Processor ARK ID	40800
Processor package size	42.5 x 45 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	455.3 mm
Width	167.9 mm
Height	450.2 mm
Weight	13500 g
