HP Z400

LSI 9212 4-Port SAS 6Gb/s
RAID Card
PCI Bus 8-lane, 5GT/s PCI Express 2.0
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 1E and 10
PCI Data Burst Transfer
Rate
Half Duplex, x4 PCIe 2000 MB/s
Full Duplex, x8 PCIe 4000 MB/s
SAS Bandwidth Half Duplex Single lane - 600 MB/s
Wide Port (2 lanes) - 1200 MB/s
Wide Port (4 lanes) - 2400 MB/s
Full Duplex Single SAS Lane - 1200 MB/s
Wide Port (2 lanes) -2400 MB/s
Wide Port (4 lanes) - 4800 MB/s
PCI Card Type 3.3V Add-in card
PCI Voltage 12 V ± 10%
PCI Power 13.5 Watts
Bracket Full height and Low-profile
Certification Level PCI-Express 2.0
IO Bus 1x4 6Gb/s SAS ports
SAS Processor LSISAS2008
Internal Connectors Four x1 SATA
External Connectors None
Maximum Number of SCSI
Devices
256
LED Indicators Internal
Activity/Fault per x4 port - Heartbeat
LSI MegaRAID® SAS
8888ELP Host Bus
Adapter (HBA)
PCI Bus PCI-Express x8 lanes
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, and 5
RAID spans 10 and 50
PCI Data Burst Transfer
Rate
Up to 3Gb/s per port
Full Duplex Up to 1.5 GB/s
PCI Voltage +3.3V Add-in Card
PCI Power 19.2 Watts Maximum
Certification Level PCI-Express 1.0a
IO Bus Eight 3Gb/s SAS/SATA ports
Internal Connectors Two SAS SFF8087 x4
External Connectors Two SAS SFF8088 x4
Maximum Number of SCSI
DeviceS
32
QuickSpecs
HP Z400 Workstation
Technical Specifications - Hard Drive Controllers
DA - 13276 North America — Version 58 — November 21, 2013 Page 39
