For Alt-mode:
Connect the Type-C end of a USB cable to a USB Type-C port on the monitor and the other end to a
USB Type-C port on the source device.
NOTE: To set the video input source to USB-C, press the Menu button under the right side of the bezel,
select Input Control, and then select USB-C Conguration.
●
Select the option 3840 × 2160 @ 60 Hz + USB 2.0 for a higher vertical refresh rate and a lower USB
speed.
– or –
●
Select the option 3840 × 2160 @ 30 Hz + USB 3.0 for a lower vertical refresh rate and a higher USB
speed.
4. Connect one end of a USB cable to a USB Type-A port on the monitor and the other end to the USB port
on a downstream source device.
Setting up the monitor 7
