HP Z820 Series User Manual

3 Setting up the workstation
This chapter describes how to set up your workstation.
Topics
Ensuring proper ventilation on page 20
Setup procedures on page 22
Adding monitors on page 23
Converting to desktop configuration (Z220 CMT and Z420)
on page 29
Ensuring proper ventilation
Proper ventilation for the system is important for workstation operation. Follow these guidelines:
●
Operate the workstation on a sturdy, level surface.
●
Provide at least 15.24 cm (6 inches) of clearance at the front and back of the workstation.
(Workstation models vary.)
Figure 3-1 Proper workstation ventilation
20 Chapter 3 Setting up the workstation

HP Z820 Series Specifications

General

Chipset	Intel C602
Memory Slots	16 DIMM slots
Processor Options	Intel Xeon E5-2600 series
Memory	Up to 512 GB DDR3
Storage Options	SATA, SAS, SSD
Graphics Options	NVIDIA Quadro, AMD FirePro
Networking	Integrated Intel 82579LM Gigabit Ethernet
Power Supply	1125W 85% efficient
Operating System	Red Hat Enterprise Linux
