HP ZR30w Technical Specifications

Cable Management Enhanced cable management for easy concealment of power, video and USB
cables. Effortless routing of cables through the base of the column with
removable cover plate.
Detachable Stand Stand ships detached and easily attaches with the HP Quick Release.
Tilt Range -5° to + 35° vertical
Swivel Range 45°L / 45°R
Height Adjustable Yes, 100 mm
Environmental Temperature – Operating 5° to 35° C (41° to 95° F)
Temperature – Non-
operating
-20° to 60° C (-4° to 140° F)
Humidity – Operating 10% to 80% non-condensing
Humidity – Non-operating 5% to 95%
Altitude – Operating +0 to 5,000 m (16,404 ft)
Altitude – Non-operating +0 to 12,192 m (40,000 ft)
Environmental Data Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
IT ECO declaration
Energy Consumption
(in accordance with US
Energy Star test method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 119.8W 117.5W 120.7W
Sleep 0.75W 0.85W 0.74W
Off 0.55W 0.65W 0.56W
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 410 BTU/hr 402 BTU/hr 413 BTU/hr
Sleep 3 BTU/hr 3 BTU/hr 3 BTU/hr
Off 2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 20.4% post-consumer recycled plastic (by wt.)
This product is 99.2% recycle-able when properly disposed of at end of
life.
QuickSpecs
HP ZR30w 30-inch S-IPS LCD Monitor
Technical Specifications
DA - 13635 North America — Version 9 — January 29, 2013 Page 4

HP ZR30w Specifications

General

3D	No
Pixel pitch	0.2505 x 0.2505 mm
Display surface	Matt
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Viewable size diagonal	762 mm
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	370 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	China
Market positioning	Business
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	185 W
Cables included	AC, DisplayPort, DVI, USB
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	276 mm
Height (with stand)	489 mm
Depth (without stand)	87 mm
Width (without stand)	694 mm
Height (without stand)	454 mm
Weight (without stand)	13000 g
