PUNCH MACHINE
™
The total depth range of the machine is from the
face of the punch to the back of the bottom jaw and
equals .700" (1.75 cm) maximum.
Fig. 2.8
RANGE: .700" (1.75 cm) MAX.
No. 1200PCH
