HPC Punch Machine 1200PCH - Parts List

75
PUNCH MACHINE
™
1200PCH Parts List
# Description Stock #
Card Lens
Screws-Lens
Punch Handle
Screw-Punch
Punch & Die Set
Screws-Clamp
Clamp-Die Plate
Spring-Clamp
Easy Grip Wing Nut
Ball Bearing Washer
Top
J
aw
Spring- Jaw
Bottom Jaw
Screw- Jaw
Stud- Jaw
Gauge Knob
Screw-Gauge Knob
Gauge-RH
Gauge-LH
Screw-Gauge Rest
Ball-Main Block
Screw-Ball Adjustment
Washer-Crank
Crank
Screw-Crank
Handle-Crank
Snap Ring-Lateral Shaft
Rubber Foot
Screw
Plunger Stud
Plunger Nut
Pin-Plunger
Punch Handle Mounting Screw
PCH-2001A
PCH 2002
PCH-ARM ASSY
CM-50185
PCH-2011
Sold Separately
PCH-2013
PCH-2014
PCH-2015
EGN-1
BBW-2
PCH-TJAW
PCH-2017
PCH-BJAW
PCH-2018
CM 8-1019MA
PCH-2021
PCH-2022
PCH-2025
PCH-2026
PCH-2027
PCH-2036
PCH-2037
PCH-2041
PCH-2042
PCH-2043
CM-1046
PCH-2034
CM-50133MA
CM-50134
PCH-2059
PCH-2060
PCH-2061
1.
2.
3.
4.
5.
6.& 7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
No. 1200PCH
