Insert the Punch and Die unit into position.
You can insert the triangular die unit first and
then the Punch unit (making sure the Punch key
lines up into key seat), or both pieces as one unit
(as shown above).
Fig. 5.2.3
49
™
PUNCH MACHINE
™
No. 1200PCH
