Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd
―8― HD30 Series Inverters User Manual
Item Specification
Display panel
LED display
Five LEDs display
Setting frequency, output frequency, output voltage, output current,
motor speed, output torque, switching value terminal, status
parameter, programm menu parameter and fault code etc.
LCD display Optional (HD-LCD), display operation contents in Chinese or English
Parameter copy Both LED and LCD display panel can achive quick parameter copy
Indicator 5 unit indicators, 5 status indicators
Environment
Operation temperature
-10－+40℃, air temperature fluctuation is less than 0.5℃/min
The derating value of the output current of the inverter shall be 2% for
each degree centigrade above 40℃. Max. allowed temperature is
50℃
Storage temperature -40－+70℃
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive, flammable
gases, oil mist, water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Oscillation Less than 5.9m/s
2
(0.6g)
Protection class IP20
Options
Extended I/O
Additional I/O option (HD30-EIO)
Plastic interface option (HD30-PIO)
Bus communication
PROFIBUS option (HDFB-PROFIBUS-DP)
DeviceNet option (HDFB-DeviceNet)
CAN option (HDFB-CAN)
About display panel
Status display panel (HD-LED-L)
LED display pane with potentiometer (HD-LED-P)
LCD display panel (HD-LCD)
Mounting base to panel (HD-KMB)
1 meter extension cable to panel (HD-CAB-1M)
2 meter extension cable to panel (HD-CAB-2M)
3 meter extension cable to panel (HD-CAB-3M)
6 meter extension cable to panel (HD-CAB-6M)
Enhanced protection Protective cover (HD-CK-Frame4)
Power units
Dynamic braking unit (HDBU)
Power regenerative unit (HDRU)
