Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―104― HD30 Series Inverters User Manual
No. Name Description Range
factory setting
F16.19 AO1 terminal output function selection 0
19
1
AO2 terminal output function selection
F16.21 High-speed pulse output function selection 0
19
0
0: Reversed.
1,2: Output frequency, reference frquency (0－maximum output frequency)
3: Motor RPM (0－maximum output frequency corresponding to RPM).
4: Output current (0－twice motor’s rated current).
5: Output current (0－twice motor’s rated current).
6－9: Reversed.
10: Output torque (0－3 times motor’s rated torque).
11: Output voltage (0－1.2 times inverter’s rated voltage).
12: Bus voltage (0－2.2 times inverter’s rated voltage).
13: Output power (0－twice motor’s rated power).
14: AI1 input (0－10V).
15: AI2 input (-10－10V / 0－20mA).
16: AI3 input (-10－10V / 0－20mA).
17: AI4 input (-10－10V / 0－20mA).
18,19: Output frequency, reference frequency (- 1 times－1 times maximum output frequency).
