Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―108― HD30 Series Inverters User Manual
No. Name Description Range
factory setting
12: Three-phase power supply input phase sequence.
• 0: Positive sequence, L1(R) preceding L2(S) preceding L3(T).
• 1: Negative sequence, L1(R) preceding L3(T) preceding L2(S).
13: Output voltage.
14: Output current.
15: Reserved.
16: Output torque.
17: Output power.
18: DC bus voltage.
19: Potentiometer input voltage.
20: AI1 input voltage.
21: AI1 input voltage (after disposal).
22: AI2 input voltage.
23: AI2 input voltage (after disposal).
24: AI3 input voltage.
25: AI3 input voltage (after disposal).
26: AI4 input voltage.
27: AI4 input voltage (after disposal).
28: DI6 terminal pulse input frequency.
29: AO1 output.
30: AO2 output.
31: High-speed output pulse frequency.
32: Heatsink temperature.
33: Set the line speed.
34: Reference line speed.
35－36: Reserved.
37: Process PID reference.
38: Process PID feedback.
39: Process PID error.
40: Process PID integral value.
41: Process PID output.
42: External couting value.
43: Input terminal status. Bit0－Bit8 are corresponding to DI1－DI9.
44: Output terminal status. Bit0－Bit11 are corresponding to DO1, DO2, RLY1－RLY10.
45: MODBUS communication status.
46: Actual length.
47: Total length.
48: Total time at power on (hour).
49: Total time at running (hour).
F18.15 Maximum line speed 0
65535
1000
Line speed display accuracy
0: Integer.
1: One decimal.
2: Two decimal.
3: Three decimal.
