hpmont HD30-4T015G/018P User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―142― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
d00.35
DI6 terminal pulse
input frequency
0－50000Hz *
d00.36 AO1 output 0.00－10.00V *
d00.37 AO2 output 0.00－10.00V *
d00.38
High-speed output
pulse frequency
0－50000Hz
*
d00.39 Heatsink temperature 0.0－999.9℃ *
d00.40 Setting line speed 0－max output line speed *
d00.41 Reference line speed 0－max output line speed *
d00.42 Reserved
d00.43 Reserved
d00.44 Process PID reference -100.0－100.0% *
d00.45 Process PID feedback -100.0－100.0% *
d00.46 Process PID tolerance -100.0－100.0% *
d00.47
Process PID integral
item
-100.0－100.0% *
d00.48 Process PID output -100.0－100.0% *
d00.49 External counting value 0－9999 *
d00.50 Input terminal status
Bit0－Bit8 corresponding to
DI1－DI9
0: Input terminal disconnect
with common terminal
1: Input terminal connect with
common terminal
Only using HD30-EIO can
the DI7－DI9 be enabled.
*
d00.51 Output terminal status
Bit0－Bit1 corresponding to
DO1－DO2
Bit2－Bit5 corresponding to
RLY1－RLY4
0: Output terminal disconnect
with common terminal
1: Output terminal connect
with common terminal
Only using HD30-EIO can
the RLY2－RLY4 be
enabled.
*
d00.52
MODBUS
communication status
0: Normal
1: Communication timeout
2: Incorrect data frame head
3: Incorrect data frame
checking
4: Incorrect data frame
*
