Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―77―
No. Name Description Range
factory setting
F06.45 Setting of PLC step 15 000
321
000
F06.17, F06.19, F06.21, F06.23, F06.25, F06.27, F06.29, F06.31, F06.33, F06.35, F06.37, F06.39,
F06.41, F06.43, F06.45 are used to configure the running frequency, the direction, acceleration and
deceleration time of every PLC step.
Units: PLC running frequency selection
• 0: Multi- step frequency command. The absolute value of each step frequency is the same as the
setting of multi-step frequency.
• Example: the absolute value of running frequency in PLC Step 15 is the setting value of F06.14.
• 1: Depend on F00.10. The running frequency source selectes the reference by F00.10 selection.
Tens: Operation direction selection of PLC at different steps
• 0: Forward.
• 1: Reverse.
• 2: Depend on run command. The motor’s operation direction can be alternated via external
direction command.
• If the direction is not set, the inverter will run in the direction according to last step.
Hundreds: Acceleration/deceleration time selection of PLC at different steps
• 0: Acceleration/deceleration time 1.
• 1: Acceleration/deceleration time 2.
• 2: Acceleration/deceleration time 3.
• 3: Acceleration/deceleration time 4.
F06.18 Running time of step 1 0.0
3276.7
5.0
F06.22 Running time of step 3 0.0
3276.7
0.0
F06.26 Running time of step 5 0.0
3276.7
0.0
F06.30 Running time of step 7 0.0
3276.7
0.0
F06.34 Running time of step 9 0.0
3276.7
0.0
F06.38 Running time of step 11 0.0
3276.7
0.0
F06.42 Running time of step 13 0.0
3276.7
0.0
F06.46 Running time of step 15 0.0
3276.7
0.0
F06.18, F06.20, F06.22, F06.24, F06.26, F06.28, F06.30, F06.32, F06.34, F06.36, F06.38, F06.40,
F06.42, F06.44, F06.46 define the running time of PLC at different steps.
• When set the running time to 0 at some step, it means that the PLC function of this step is
disabled.
