HS 6200 - Base Assembly Parts List

IN-6200
21
To order complete Base Assembly use P/N’s.
2716292 Chair Base Assembly - Low - 120V*
2716392 Chair Base Assembly - High - 120V*
2716492 Chair Base Assembly - Low - 230V*
2716592 Chair Base Assembly - High - 230V*
*Please specify paint color when ordering.
NOTE- Power cord for 230V base does not
include a plug.
NOTE- Le cordon de secteur pour la base
230V ne comprend pas une fiche.
ITEM
PART NO.
DESCRIPTION
ITEM PART NO.
DESCRIPTION
1
2081203 Base
20
0560099 Thrust Washer
2
2065599 Base Cover
21
0123885 Lock Nut
3
2065199 Base Housing - Low - RH
22
1548195 Wiring Tube-High
2065399 Base Housing - High - RH 1548395 Wiring Tube-Low
4
2065299 Base Housing - Low - LH
23
1127599 Union Tee
2065499 Base Housing - High - LH 24 1659299 Power Cord Assembly
5
Lift Assembly (See Figure 10) 25 1550599 Chair Control Cable-LV To LV
6
1707792 Solenoid Valve Assembly-120V
26
1608292 Footswitch Assembly
1707892 Solenoid Valve Assembly-230V
27
1634299 Fuse, 6.3 A / 250V-120V
7
1702892 Keyshield Assembly-Low* 1634999 Fuse, 4 A / 250V-230V
1702992 Keyshield Assembly-High*
28
1976799 Power Entry Module W/ Filter
8
2720092 Pump/Motor Assembly-120V 29 Fusedrawer, 2 Pole (In Item 28)
2720192 Pump/Motor Assembly-230V 30 0458999 Tubing-5 in
9
1547899 Piston Rod Bolt
31
1597299 Capacitor, Starting-120V
10
1525899 Set Screw-#10-24 x 1/4 2002199 Capacitor, Starting-230V
11
0607299 Washer
32
1993592 Ent Transformer Assembly - 120V
12
2721092 Hose Assembly 1994392 Ent Transformer Assembly - 230V
13
1596292 Pressure Tube Assembly
33
2722099 Base Cable Grey
14
2025599 P.C. Board Assembly 34 1643899 6 Circuit Plug
15
2720892 AC Input Assembly
35
1643799 4 Circuit Plug
16
0458999 Tubing-5-1/2 in
36
1720399 PH Phil w/Lock Washer-#10-24 x 1/2
17
1081999 Tubing Insert
37
2081099 Housing Mount Bracket
18
1547999 Snap Bushing
38
0708599 HHCS 3/8-16 x 1.5
19
0559999 Thrust Bearing
39
1569999 Circuit Board Support
