IN-6200
25
To order complete Headrest Assembly use P/N. To order complete Screw Assembly use P/N.
144080 #18 Headrest Assembly* 2721692 Middle Joint Screw Assembly
144070 #22 Headrest Assembly* Includes: Item’s 5, 6, 7 & 8.
*Please specify paint color when ordering. 2721792 Bottom Joint Screw Assembly
** Please specify upholstery color when ordering.
Includes: Item’s 5, 6, 8 & 18
ITEM PART NO. DESCRIPTION
1
0475673 Pad Assembly - No. 18*
1680073 Pad Assembly - No. 22*
2 1460492 Yoke Assembly*
3 1460592 Gear & Bracket Assembly*
4 1470692 Actuator & Lock Gear Assembly
5 1425299 Pivot Cap, Right
6 1425399 Pivot Cap, Left
7 0307599 Screw, Shoulder 1/4 x 1
8 0726099 S.H.S.S. #10-24 x 3/16
9 1424999 Washer, 2" OD
10 1454799 B.H.C.S. 1/4-28 x 1/2
11 1456399 S.H.S.S. #10-24 x 3/8
12 1427099 Spring Plunger
13 1538899 Spring
14 1454999 L.H.C.S. #10-24 x 3/4 - Socket
15 1434799 Pivot Cap, Pad
16 0467195 Bushing .188 I.D x .312 O.D.
17 1456199 Nut, Acorn 1/4-20 Low Crown
18 1425699 Screw, Shoulder .25 x .50
