HT HT3300 - Technical Specifications; Reference Guidelines; General Characteristics; Environmental Conditions for Use

HT3300
EN - 9
7. TECHNICAL SPECIFICATIONS
Accuracy indicated as [±(%reading) or ±degrees]
INFRARED TEMPERATURE MEASUREMENT (Autorange)
Function Range Resolution Accuracy Response time
°C
-50.0°C  20.0°C
0.1°C
±2.5°C
<150ms
20.0°C  380.0°C
±(1%rdg + 1°C)
°F
-58.0°F  68.0°F
0.1°F
±4.5°C
68.0°F  716.0°F
±(1%rdg + 1.8°F)
Reading repeatability: ±1°C / ±1.8°F
Spectrum response: 8  14m
D/S ratio: 12:1
IR sensor: thermopile
Allows emissivity: >0.95
Laser: double pointer (<1mW, Class 2 compliance with IEC/EN60825-1)
Over range indication: “----“ symbol at display
7.1. REFERENCE GUIDELINES
EMC: IEC/EN61326-1
Laser source: IEC/EN60825-1, Class 2
Max operating altitude: 2000m (6592ft)
7.2. GENERAL CHARACTERISTICS
Mechanical specifications
Size (L x W x H): 136 × 75 × 40mm (5 x 3 x 2in)
Weight (battery included): 140g (5ounces)
Power supply
Battery type: 1x9V alkaline batteries type IEC 6F22
Low battery indication: symbol " " appears on display
Auto Power OFF: after 10 seconds' idleness
Display
Characteristics: 4 LCD, Custom, backlit
7.3. ENVIRONMENTAL CONDITIONS FOR USE
Operating temperature: 0°C  50°C (32°F  122°F)
Operating humidity: 10  90%RH
Storage temperature: -10°C  60°C (14°F  140°F)
Storage humidity: <80%RH
This instrument complies with Directive EMC 2004/108/EC
This instrument complies with European Directive 2011/65/EU (RoHS)
and 2012/19/EU (WEEE)
7.4. ACCESSORIES PROVIDED
 Soft transport bag
 Battery
 User manual
