HTC 280 - Technical Data

Storage of the product
• Keep the product in a locked area to prevent access
for children or persons that are not approved.
• Keep the product in a dry and frost free area.
Technical data
Technical data
Single-phase, 220-240V Single-phase, 100-120V
Motor 50 Hz 60 Hz 50 Hz 60 Hz
Motor power, kW/hp 2.2/3.0 2.2/3.0 1.5/2.0 1.1/1.5
Rated current, A 13 13 20 15
Rated voltage, V 220-240 220-240 100-120 100-120
Weight, kg/lbs 72/158 72/158 72/158 74/163
Grinding width,
mm/in.
280/11 280/11 280/11 280/11
Grinding pressure,
kg/lbs
25/55 25/55 25/55 20/44
The speed that the
tool plate rotates,
rpm
1410 1730 940 1150
18 917 - 001 -
