HTP Versa Hydro PHE130 Series User Manual

LP-314 Rev. 012 Rel. 003 Date 9.27.19
39
Left < and Right > ARROW Keys – The right and left arrow keys (<
and >) are used to navigate between the default Display and Status
Display. The < and > keys are also used in programming modes to
change between programmable parameters. It is recommended
you use the Menu Maps in the back of this manual and the detailed
menu instructions printed in this section to help in menu navigation.
Up ^ and Down v ARROW Keys – The up and down (^ and v) arrow
keys are used to navigate between the various parameters displayed
in the menu. After the parameter is enabled for editing by pushing
the ENTER key, the ^ and v keys are used to adjust the parameter
upward or downward to the desired value.
B. Programming the Control
Program Access
Note: Programming the control is not possible when the appliance
is ring. Make sure any input which can create a demand on the
appliance, such as the thermostat, is turned o, so the appliance will
remain idle to allow programming.
Screen Description
ENTER MENU CODE
000
To access the setting program, press
and hold ENTER for 4 seconds until the
display shows the screen at left.
ENTER MENU CODE
600
Use the arrow keys to log in the Access
Code - 600. Press ENTER to conrm the
code and access the Program navigation
menu.
Table 13 - Program Setting Access
Appliance Setting Program Navigation
Once the code is conrmed, the user can start to set the Appliance
Settings. Use the arrow keys on the display to navigate through the
Appliance Settings. A blinking setting indicates the setting can
be changed. To change a setting, press ENTER. Appliance settings
can be increased by pressing ^ and decreased by pressing v on the
display. When done, press ENTER. The setting will stop blinking and
the user can move on to next setting by pressing the < or > arrow
keys. Press RESET to exit programming and store settings. Listed
below are the settings that can be programmed into the control.
Screen Description
CENTRAL HEAT
140
o
F
Allows the user to adjust the central
heating set point from 50F to 140
o
F
(Factory Default 140
o
F).
HEATING DELTA T
20
o
F
Adjusts the central heating delta T set
point from 5
o
F to 30
o
F (Factory Default
20
o
F).
DHW SETPOINT
119
o
F
Adjusts the DHW set point from 95 to
180
o
F (Factory default 119
o
F). NOTE: The
appliance is supplied with a thermostatic
mixing valve that must be installed on
to the domestic hot water system. Any
changes in this set point will also require
adjustment to the mixing valve. Please
refer to the mixing valve section in
Domestic Water Piping, this manual, for
further setup and operation details.
BURNER RUN OFFSET
5
o
F
Adjusts the oset from the current target
tank temperature where the control will
begin heating water. Range: 1 to 18
o
F
(Factory default 5
o
F).
TEMP DISPLAY C OR F
o
F
Adjusts the temperature measurement in
F = Fahrenheit to C = Celsius (Default is
Fahrenheit).
Table 14 - Appliance Setting Program Navigation
Clock Settings
(NOTE: The clock will reset if the appliance is powered o for more
than a week.)
Screen Description
CLOCK MODE (12/24)
08/28/2009 Fr 9:42A
Changes the clock from 12 hour mode
(8:45 PM) to 24 hour mode (20:45). To
change to 24 hour mode, press ENTER.
The letter (A or P) after the time will blink.
Press the up or down arrow key once and
the letter will disappear. Press ENTER to
save the new setting.
CLOCK HOUR
08/28/2009 Fr 10:01A
Allows the user to adjust the hour setting.
CLOCK MINUTE
08/28/2009 Fr 10:01A
Adjusts the minute setting.
CLOCK DAY OF WEEK
08/28/2009 Fr 10:01A
Adjusts the day of the week.
CLOCK DATE MODE
08/28/2009 Fr 10:01A
Allows the user to switch to European
date format (2009/08/28) from US format
(08/28/2009).
CLOCK YEAR
08/28/2009 Fr 10:01A
Adjusts the year setting.
CLOCK MONTH
08/28/2009 Fr 10:01A
Adjusts the month setting.
CLOCK DATE
08/28/2009 Fr 10:01A
The clock is set.
Table 15 - Clock Setting Screens
NOTE: The internal clock does not adjust for daylight savings time and
requires manual adjustment.
C. Programming the System Setting
System Setting Program Access
Note: Programming the control is not possible when the appliance
is ring. Make sure any input which can create a demand on the
appliance, such as the thermostat, is turned o, so the appliance will
remain idle to allow programming.
Screen Description
ENTER MENU CODE
000
To access the system setting program,
press and hold ENTER for 4 seconds until
the display shows the screen at left.
ENTER MENU CODE
925
Use the arrow keys to log in the System
Menu Access Code - 925. Press ENTER to
conrm the code and access the System
Setting Program navigation menu.
Table 16 - System Setting Access
D. System Setting Program Navigation
Once the System Menu Access Code is conrmed, the user can begin
to set the system settings. Use the < > keys on the display to navigate
through the System Settings. To change a setting, press ENTER. System
settings can be increased by pressing ^ and decreased by pressing v
on the display. When done, press ENTER. The setting will stop blinking
and you can move on to next setting. Press RESET to exit programming
and store settings. Listed below are the appliance settings that can be
programmed into the control.
Screen Description
Function 1 Factory Program Mode
MODE
PHOENIX 1
This indicates that the control is congured
correctly. Do not change this setting.
