Table 1-1 AISU specifications
Azimuth Precision (°)* ±2
Mechanical Tilt Precision
(°)
±0.5
Horizontal Positioning
Precision (m)*
< 6
Vertical Positioning
Precision (m)*
< 3
Protocol Compliance
AISG-ES-RAE V2.1.0
Input Voltage Range (V)
10 to 30 (DC)
Power Consumption (W)
< 2.5 (@ 12 V)
Connector
8-pin male connectors compliant with the IEC 60130-9 standard
Connector Pin
1 2 3 4 5 6 7 8
DC n/c RS-485B n/c RS-485A DC DC return n/c
Device Weight (kg)
0.85
Packing Weight (kg) 1.9
Operating Temperature (°C) -40 to +65
Surge Protection
Specifications (kA)
5 (8/20 μs)
Ingress Protection Rating
IP65
Device Dimensions (H x W
x D) (mm)
37 x 325 x 129 (including connectors and not including mounting
brackets)
Packing Dimensions (H x W
x D) (mm)
100 x 470 x 187.5
* indicates that the item is affected by the multipath environment, number of visible satellites,
satellite geometric distribution, ionospheric activeness, and SBAS using and observation time.
1.3 Appearance Description
The AISU contains only one AISG male connector.
