Huawei AP5030DN

Huawei AP5030DN Access Points
Product Description
2 Hardware Structure
Issue 01 (2014-04-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
2 Hardware Structure
About This Chapter
2.1 AP5030DN
2.1 AP5030DN
Appearance
Figure 2-1 shows AP5030DN appearance.
The actual device appearance may be different from the following device appearance, but these
differences will not affect device functions.
Figure 2-1 AP5030DN appearance
